| Project |
Unit |
VMC550 |
VMC630 |
VMC800 |
| Ⅰ |
Ⅱ |
Ⅰ |
Ⅱ |
|
| Bench |
|
| Working desk size |
mm |
550*1200 |
550*1500 |
630*1400 |
630*1600 |
800*2200 |
| T-slot |
mm |
5*18*100 |
5*18*100 |
7*18*100 |
7*18*100 |
7*18*1 |
| Workbench maximum load |
kg |
1000 |
1200 |
1200 |
1500 |
2000 |
| Travel |
|
| X-axis travel |
mm |
1200 |
800 |
1300 |
1100 |
1400 |
| Y-axis travel |
mm |
550 |
650 |
850 |
| Z-axis travel |
mm |
650 |
800 |
800 |
| Spindle nose to table distance |
mm |
200-850(customizable） |
200-1000(customizable） |
200-1000（customizable） |
| Spindle |
| Spindle speed |
rpm |
6000 |
6000 |
6000 |
| Spindle taper |
|
BT50 |
BT50 |
BT50 |
| Main motor power |
Kw |
15Kw |
18.5Kw |
22Kw |
| Spindle twist rejection |
n.m |
95 |
117 |
141 |
| Feed system |
| X-axis rapid movement |
m/min |
32 |
32 |
32 |
| Y-axis rapid movement |
m/min |
32 |
32 |
32 |
| Z-axis rapid movement |
m/min |
32 |
32 |
32 |
| Cutting feed rate |
mm/min |
1-12000 |
1-12000 |
1-12000 |
| X, Y, Z transmission motor power |
Kw |
3/3/4 |
3/3/4 |
3/3/4 |
| Track form |
|
Three-axis rail |
Three-axis rail |
Three-axis rail |
| ? ? ? ? ? ? ? Accuracy |
| Full positioning accuracy |
mm |
0.01 |
0.01 |
0.01 |
0.01 |
0.01 |
| Repeatability |
mm |
0.005 |
0.005 |
0.005 |
0.005 |
0.005 |
| Automatic tool change system |
| Tool magazine capacity |
|
24 |
24 |
24 |
24 |
24 |
| Tool diameter (full knife) |
mm |
φ110 |
φ110 |
φ110 |
φ110 |
φ110 |
| Maximum tool diameter (lead empty knife) |
mm |
φ250 |
φ250 |
φ250 |
φ250 |
φ250 |
| Maximum?Tool length |
mm |
300 |
300 |
300 |
300 |
300 |
| Maximum Tool weight |
kg |
15 |
15 |
15 |
15 |
15 |
| Tool change time (knife to knife) |
sec |
3 |
3 |
3 |
3 |
3 |
| Air supply (use pressure) |
kg/cm2 |
6 |
6 |
6 |
6 |
6 |
| Machine weight |
kg |
9000 |
9000 |
10000 |
10000 |
12000 |
| CNC system |
FANUC system、SIEMENS system、Mitsubishi system |
